Features：
◆ Use High Precision HINWIN Linear Guide
◆ Spindle Speed 60000rpm
◆ Drilling Offset Accuracy Is ≤0.02mm
◆ Can Drilling Single Side,Double Side /Multi Layer PCB,MCPCB
Machine Technical Parameters：
Mode | KX-ZBB20 |
Process Area: | 580*1000mm |
Drilling Hole Dia: | 0.08-3.5mm |
Drilling Precision: | Center deviation ≤0.02mm Aperture deviation≤0.025mm |
Drilling Speed | （20-40）Holes/min |
Power: | 220V±10%(single phase) 2.5KVA |
Air Pressure: | ≥0.5mpa |
Machine Size: | 1180*800*1280mm |
Machine Weight: | 250kg |
Spindle Speed : | 60000RPM |
Spindle Power: | 1200W |
Tool change way | Pneumatic tool change |
