Principles PCB V-Cut machine

The PCB V-Cut machine operates based on the principle of using rotary cutting blades or laser beams to create V-shaped grooves in specific locations on the circuit board. These V-shaped grooves are designed to facilitate the subsequent separation of the SMT circuit boards after assembly. Specifically, there are two main implementations of the V-Cut machine:

1. Mechanical V-Cut Board Separator: This type of machine uses a rotary cutting blade to separate the boards along the pre-cut V-shaped grooves. During the separation process, the machine aligns the V-shaped groove with the circular blade and applies force to push the blade through, effectively cutting the board at the V-Cut location. Some machines feature automatic board feeding and blade movement, requiring only a single button press to initiate the cutting process.






2. PCB V-CUT Technology: This technology utilizes lasers and robots to perform the cutting of circuit boards. The laser beam scans the surface of the circuit board, and based on pre-designed circuit and contour information, the robot is controlled to complete the cutting on the circuit board. This technology enables high-speed, high-precision, and error-free cutting, suitable for processing various shapes, sizes, and quantities of circuit boards.

Functions PCB V-Cut machine

1. Improve production efficiency: The PCB V-Cut machine can quickly and accurately complete the cutting of circuit boards, significantly improving production efficiency.

2. Reduce labor costs: With automated operation, the need for manual intervention is reduced, thereby reducing labor costs.




3. Improve product quality: The V-Cut machine maintains consistent quality during the cutting process, avoiding issues such as board warping and component breakage that may occur due to uneven force application during manual operation. This improves product yield and reliability.

4. Facilitate subsequent operations: The V-shaped grooves created by the V-Cut machine make it easier to separate the boards during subsequent operations, enhancing the overall efficiency of the production line.
